图王CB15 60度刻字刀片｜规格、选型与官方型号对照

答案摘要：图王CB15 60度刻字刀片是本页供应资料所列的1.5 mm刀杆切割刀，标注长度23 mm、偏心距0.25 mm、最大材料厚度0.25 mm和5片装。页面没有足以验证“进口”或Graphtec原装身份的文件。Graphtec America当前官方刀片目录列有CB15U、CB15U-K30和CB09UB-K60，但未列出名为“CB15 60°”的官方型号，因此订购前必须以实物尺寸、刀座和设备说明确认适配。

图王CB15 60度刻字刀片：页面所列参数

项目	本页供应资料
刀尖角度	60°；同系列文字另列30°和45°
刀杆直径	1.5 mm
总长度	23 mm
偏心距	0.25 mm
标称最大材料厚度	0.25 mm
硬度	91.5 HRA（供应资料标称）
抗弯强度	4000–4200 N/mm²（供应资料标称）
包装	5片/盒

硬度、抗弯强度、产地和品牌身份均未展示独立检测报告、追溯编号或授权文件，以上信息应当视为供应资料，而不是第三方认证结论。

与Graphtec官方刀片目录怎样对照？

Graphtec America官方刀片目录当前列出CB15U、CB15U-K30、CB15UA、CB15UA-K30以及CB09UB-K60等型号。官方页面把CB15U描述为适合0.25–0.5 mm较厚或较硬介质，把CB09UB-K60描述为适合不超过0.25 mm的薄膜。官方目录没有把“CB15 60°”作为独立型号列出，因此不能仅凭本页名称断定它是Graphtec原装产品，也不能直接套用官方型号的适配范围。

选型、安装与试切

1. 核对刀杆：测量现用刀片并确认刀座接受1.5 mm刀杆，同时确认23 mm总长度。
2. 核对刀座与设备：查看设备手册中允许的刀片系列、夹持尺寸和偏心设置。
3. 控制刀尖外露：仅露出足以切透面材的长度，避免用过度外露补偿刀压或刀片磨损。
4. 从保守参数试切：在废料上测试方形、圆形和细小转角，然后逐步调整刀压、速度和offset。
5. 记录结果：记录材料、厚度、速度、刀压、偏心距和排废表现，便于复现与排查。

更多1.5 mm刀杆规格可查看站内大图王刻字刀系列。

产品图片识别

常见问题

这款CB15 60度刀片是否为Graphtec原装？

现有页面无法证明。若采购条件要求原装，应索取可核验的品牌包装、零件编号、授权渠道或追溯文件。

60度一定适合厚材料吗？

不能只凭角度判断。材料结构、硬度、刀尖几何、刀杆、刀座、刀压和设备能力共同决定结果。本页只标注最大0.25 mm，实际仍需试切。

为什么官方目录中的K60是CB09UB-K60？

Graphtec官方目录按具体型号区分刀杆系列与用途。本页名称是CB15 60度，但并没有官方型号证据，所以必须分别理解。

切不透或转角变形怎么检查？

先清理刀座、检查刀尖磨损和刀座旋转，再检查刀尖外露、刀压、速度与偏心补偿；不要只持续增加刀压。

English technical reference for a 1.5 mm, 60 degree blade listing

Quick answer: This page lists a 60 degree cutting plotter blade described as CB15 style, with a 1.5 mm shank, 23 mm overall length, 0.25 mm offset, and five pieces per box. The page supplier data states a maximum media thickness of 0.25 mm. These are listing-specific statements. They do not establish imported origin, genuine Graphtec manufacture, or compatibility with every Graphtec cutter.

Identity and official-model caution

Graphtec America’s current blade directory lists CB15U, CB15U-K30, CB15UA, CB15UA-K30, and CB09UB-K60. It does not present a product named CB15 60 degree in that directory. The official CB15U is described for rigid or thicker media from 0.25 to 0.5 mm, while the official CB09UB-K60 is described for thin film up to 0.25 mm. Those official descriptions concern Graphtec’s identified parts and must not be transferred automatically to the blade offered on this page.

The 60 degree tip angle on this listing is therefore a selection characteristic, not proof of an official part number. The 1.5 mm diameter and 23 mm length should be physically compared with the installed blade and holder. If a machine manual requires a named Graphtec part, obtain a traceable part number and genuine supply evidence instead of relying on a similar product title.

Supplier-reported mechanical values

The page reports hardness of 91.5 HRA and flexural strength of 4000–4200 N/mm². No independent laboratory report is displayed, so these values should be treated as supplier-reported specifications. The same caution applies to origin and brand claims. Buyers working under a certified production process should request documented material verification, batch traceability, and dimensional inspection records where required.

Compatibility checklist

Confirm that the holder accepts a 1.5 mm shank and that the 23 mm length can be clamped without interference. Confirm the machine’s supported blade family and offset-control method. Inspect the holder for free rotation and adhesive contamination. Use the stated 0.25 mm offset only as an initial reference; software and device compensation may require a different practical setting. Do not assume that two blades with similar names share the same holder or geometry.

Controlled test-cut procedure

Install the blade with the smallest practical tip exposure. Use scrap from the actual production material. Begin with conservative force and speed, then cut a small square, circle, and corner detail. The face layer should separate cleanly while the liner remains substantially intact. If corners do not close, check offset, holder rotation, debris, and blade wear before raising force. If the liner is deeply scored, reduce exposure or force and retest.

Record material name, measured thickness, blade batch, holder type, speed, force, offset, and test outcome. A short acceptance record makes later repeat jobs more reliable. Replace the blade when cleaning and setting changes no longer restore consistent corners and weeding. Protect carbide tips from drops or side impact, and clean adhesive residue without forcing the holder bearing.

Purchase conclusion

This listing may be evaluated when a machine uses a compatible 1.5 mm blade system and the buyer can verify the 23 mm length, 60 degree tip, and holder fit. It should not be purchased solely because the title uses CB15 or Graphtec-related wording. Use physical measurement, the machine manual, supplier confirmation, and a controlled test cut together. When genuine Graphtec origin is mandatory, buy by an official part number through a verifiable authorized channel.
